VIS-3000 – Access Control Indoor + Outdoor Rated IP68 Metal Anti Vandal Digital Touch Keypad + Reader Standalone + Wiegand 26 Wide Design No Software EM + Mifare Cards Compatible 2000 Users
The device is a metal access control keypad and proximity card reader which supports EM, MF and HID card types, it’s one of the most advanced standalone access control.
It adopts a unique design with metal material and durable backlight metal keyboard, builds-in USA Atmel microprocessor, with strong anti-interference ability, high security and reliability, powerful function and convenient operation. It’s widely used in high-end buildings, residential communities and other public places.
- Ultra-low power consumption: Standby current is less than 30mA.
- Input & Output: Wiegand26.
- Searching Time: Less than 0.1s after reading card.
- Backlight Keypad: Easy to operate at night.
- Doorbell interface: Support external wired doorbell.
- Access ways: Card, code, card+code.
- Independent codes: Use codes without related card.
- Change Codes: Users can change codes by themselves.
- Anti-tamper alarm: Alarm is activated after tear down illegally.
- Delete Users by card NO.: Delete card NO. by keypad to eliminate security risk completely.
- Waterproof Rate: IP68, indoor or outdoor use.
|Input Voltage||DC 12V|
|Card Reading Distance||2 - 3 cm (0.78 - 1.18 in.)|
|Card Frequency||125KHz for EM and HID // 13.56MHz for Mifare|
|Card Transmission Format||Wiegand26|
|Keypad Transmission Format||4bit, 8bit and Virtual card number|
|Operating Temperature||-45°C ～55° C (-49°F ～131°F)|
|Product Size||118Lx81Wx21H (mm) - 4.64Lx3.18Wx0.82H (in.)|
|Protection Level||IP68 - No ingress of dust; complete protection against contact (dust tight), and waterproof|
